Capabilities

Commercial Aircraft

ATR 42-300/320

Model No.

14SF-5/-7

Prop CMM

61-13-02

Control

782490-40 782490A40 782490-51 782490A51

Propeller

792000-3 792000-4 802255-1

Hub

782701-4 782701-5

EPC

785087-1-006 785087-6-013

Transfer Tube

814829-1 782515-1

Adjusting Nut

N/A

Retaining Rings

794345-1

Actuator

790180-2 790180-3

Blade & Pin

SFA13G1R0A SFA13M1R0A SFA13M1P0A SFA13U1R0A SFA13U1P0A

Slip Ring

N/A

Bulkhead

784914-3

Spinner

790176-1

Dome Cover

N/A

Brush Block

(CMM 61-21-04) 782689-2 782689-4 782689-6

ATR 42-400

Model No.

568F-1

Prop CMM

61-13-12

Control

N/A

Propeller

815500-2 815500-3

Hub

815470-1 815470-2

EPC

816332-2 816332-3 816332-101

Transfer Tube

815587-1 815587-3

Adjusting Nut

815540-1 814754-1

Retaining Rings

N/A

Actuator

815585-2 815585-3 815585-4 815585-5 815585-6 815585-7

Blade & Pin

R815505-2 R815505-3 R815505-6 R815505-9 R815505-10 R815505R2 R815505R3 R815505S3 R815505R2W R815505S3W R815505R3W

Slip Ring

817579-2

Bulkhead

810591-1

Spinner

810592-1

Dome Cover

815531-1

Brush Block

(CMM 61-21-16) 817536-1 817536-2 820538-1

ATR 42-500/-600 (S)

Model No.

568F-1

Prop CMM

61-13-12

Control

N/A

Propeller

815500-2 815500-3

Hub

815470-1 815470-2

EPC

816332-2 816332-3 816332-002 816332-003

Transfer Tube

815587-1 815587-3

Adjusting Nut

815540-1 814754-1

Retaining Rings

N/A

Actuator

815585-2 815585-3 815585-4 815585-5 815585-6 815585-7

Blade & Pin

R815505-2 R815505-3 R815505-6 R815505-9 R815505-10 R815505R2 R815505R3 R815505S3 R815505R2W R815505S3W R815505R3W

Slip Ring

817579-2

Bulkhead

810591-1

Spinner

810592-1

Dome Cover

815531-1

Brush Block

(CMM 61-21-16) 817536-1 817536-2 820538-1

ATR 72-200

Model No.

14SF-11

Prop CMM

61-13-06

Control

782490-11 782490A11 782490-40 782490A40 782490-51 782490A51

Propeller

794300-1 802250-1 802325-1 806660-1 806660L1

Hub

802308-1 802396-1

EPC

785087-1-006 785087-1-007 785087-2-009 785087-6-013

Transfer Tube

814829-1 782515-1

Adjusting Nut

N/A

Retaining Rings

802227-1

Actuator

790180-2 790180-3

Blade & Pin

SFA13J1R0A SFA13K1R0A SFA13N1R0A SFA13S1R0A SFA13N1P0A SFA13S1P0A

Slip Ring

N/A

Bulkhead

784914-3

Spinner

790176-1

Dome Cover

N/A

Brush Block

(CMM 61-21-04) 782689-2 782689-4 782689-6

ATR 72-200 (Elec)

Model No.

14SF-11E

Prop CMM

61-13-06

Control

N/A

Propeller

815590-1

Hub

802308-1

EPC

816331-1 816331-2 816331-001

Transfer Tube

810461-1

Adjusting Nut

N/A

Retaining Rings

810480-1

Actuator

790180-3

Blade & Pin

SFA13S1P0A SFA13S1R0A

Slip Ring

N/A

Bulkhead

814844-1 814844-2

Spinner

811107-1

Dome Cover

N/A

Brush Block

(CMM 61-21-04) 782689-6

ATR 72-210

Model No.

247F-1

Prop CMM

61-13-11

Control

N/A

Propeller

810610-2

Hub

810447-1 810449-1

EPC

785087-3-010 785087-3-011 785087-4-011 785087-4-014

Transfer Tube

810461-1

Adjusting Nut

N/A

Retaining Rings

810480-1

Actuator

R810510-1 R810510-2 R810510-3

Blade & Pin

R817370-1 R817370R1

Slip Ring

N/A

Bulkhead

810443-2

Spinner

811107-1

Dome Cover

N/A

Brush Block

(CMM 61-21-04) 782689-4 782689-6

ATR 72-210 (Elec)

Model No.

247F-1E

Prop CMM

61-13-11

Control

N/A

Propeller

815550-2

Hub

810447-1 810449-1

EPC

804820-5 804820-6 804820-001 804820-002 804820-003

Transfer Tube

810461-1

Adjusting Nut

N/A

Retaining Rings

810480-1

Actuator

R810510-2 R810510-3

Blade & Pin

R817370-1 R817370R1

Slip Ring

N/A

Bulkhead

814844-1 814844-2

Spinner

811107-1

Dome Cover

N/A

Brush Block

(CMM 61-21-04) 782689-4 782689-6

ATR 72-210A/-500/-600(F)

Model No.

568F-1

Prop CMM

61-13-12

Control

N/A

Propeller

815500-2 815500-3

Hub

815470-1 815470-2

EPC

816332-2 816332-3 816332-101

Transfer Tube

815587-1 815587-3

Adjusting Nut

815540-1 814754-1

Retaining Rings

N/A

Actuator

815585-2 815585-3 815585-4 815585-5 815585-6 815585-7

Blade & Pin

R815505-2 R815505-3 R815505-6 R815505-9 R815505-10 R815505R2 R815505R3 R815505S3 R815505R2W R815505S3W R815505R3W

Slip Ring

817579-2

Bulkhead

810591-1

Spinner

810592-1

Dome Cover

815531-1

Brush Block

(CMM 61-21-16) 817536-1 817536-2 820538-1

CL-215T /-415

Model No.

14SF-17

Prop CMM

61-13-07

Control

782490A37 782490A48

Propeller

802375-1

Hub

802308-1

EPC

N/A

Transfer Tube

814829-1 782515-1

Adjusting Nut

N/A

Retaining Rings

802227-1

Actuator

790180-2 790180-3

Blade & Pin

SFA13K1R0B

Slip Ring

N/A

Bulkhead

784914-1 784914-2 784914-3

Spinner

N/A

Dome Cover

N/A

Brush Block

N/A

CL-215T /-415

Model No.

14SF-19

Prop CMM

61-13-07

Control

782490A37 782490A48

Propeller

802375-2

Hub

802308-1

EPC

N/A

Transfer Tube

814829-1 782515-1

Adjusting Nut

N/A

Retaining Rings

802227-1

Actuator

790180-2 790180-3

Blade & Pin

SFA13N1R0A-1 SFA13S1P0A-1

Slip Ring

N/A

Bulkhead

784914-1 784914-2 784914-3

Spinner

N/A

Dome Cover

N/A

Brush Block

(CMM 61-21-04) 782689-1 782689-3 782689-5

DHC 8 -100s

Model No.

14SF-7

Prop CMM

61-13-02

Control

782490-39 782490A39 782490-50 782490A50

Propeller

792000-3 792000-4 802255-1

Hub

782701-4 782701-5

EPC

N/A

Transfer Tube

814829-1 782515-1

Adjusting Nut

N/A

Retaining Rings

794345-1

Actuator

790180-2 790180-3

Blade & Pin

SFA13G1R0A SFA13M1R0A SFA13M1P0A SFA13U1R0A SFA13U1P0A

Slip Ring

N/A

Bulkhead

784914-1 784914-2 784914-3

Spinner

790176-1

Dome Cover

N/A

Brush Block

(CMM 61-21-04) 782689-1 782689-3 782689-5

DHC 8 -200s

Model No.

14SF-23

Prop CMM

61-13-06

Control

782490-39 782490A39 782490-50 782490A50 782490-36 782490A36 782490-47 782490A47 782490-39 782490A39

Propeller

806700-1

Hub

802396-1

EPC

N/A

Transfer Tube

814829-1 782515-1

Adjusting Nut

N/A

Retaining Rings

802227-1

Actuator

790180-2 790180-3

Blade & Pin

SFA13J1R0A SFA13K1R0A SFA13N1R0A SFA13N1P0A SFA13S1R0A SFA13S1P0A

Slip Ring

N/A

Bulkhead

784914-1 784914-2 784914-3

Spinner

790176-1

Dome Cover

N/A

Brush Block

(CMM 61-21-04) 782689-1 782689-5

DHC 8 -300

Model No.

14SF-23

Prop CMM

61-13-06

Control

782490-36 782490A36 782490-47 782490A47

Propeller

806700-1

Hub

802396-1

EPC

N/A

Transfer Tube

814829-1 782515-1

Adjusting Nut

N/A

Retaining Rings

802227-1

Actuator

790180-3

Blade & Pin

SFA13J1R0A SFA13K1R0A SFA13N1R0A SFA13N1P0A SFA13S1R0A SFA13S1P0A

Slip Ring

N/A

Bulkhead

784914-1 784914-2 784914-3

Spinner

790176-1

Dome Cover

N/A

Brush Block

(CMM 61-21-04) 782689-1 782689-5

DHC 8 -300s

Model No.

14SF-15

Prop CMM

61-13-06

Control

782490-36 782490A36 782490-47 782490A47

Propeller

794300-1 802250-1 802325-1 806660-1

Hub

802308-1 802396-1

EPC

N/A

Transfer Tube

814829-1 782515-1

Adjusting Nut

N/A

Retaining Rings

802227-1

Actuator

790180-2 790180-3

Blade & Pin

SFA13J1R0A SFA13K1R0A SFA13N1R0A SFA13N1P0A SFA13S1R0A SFA13S1P0A

Slip Ring

N/A

Bulkhead

784914-1 784914-2 784914-3

Spinner

790176-1

Dome Cover

N/A

Brush Block

(CMM 61-21-04) 782689-1 782689-5

EMB 120

Model No.

14RF-9

Prop CMM

61-13-03

Control

782490-35 782490-46

Propeller

780100-5 780100-6 780100-7 780100-8 780100-9

Hub

782501-4 782501-6 782501-7 814721-1 814721-2

EPC

N/A

Transfer Tube

790202 814782

Adjusting Nut

N/A

Retaining Rings

786060-1

Actuator

790201-1 790201-2 790201-3 790201-5 790201-6 790201-7 790201-8 790201-9

Blade & Pin

RFC11E1R6A RFC11M1R6A RFC11N1R6A RFC11U1R6A RFC11AA1R6A RFC11AA1P6A RFC11M1P6A RFC11N1P6A RFC11U1P6A

Slip Ring

N/A

Bulkhead

784784-1 784784-2

Spinner

790189-1 817570-1

Dome Cover

N/A

Brush Block

775689-1 775689-2 775689-4

SAAB 340B

Model No.

14RF-19

Prop CMM

61-13-09

Control

782490-19 782490-34 782490-45 782490-56

Propeller

782750-11

Hub

782501-6 782501-7 782501-8 814721-1 814721-2

EPC

N/A

Transfer Tube

784525 814799

Adjusting Nut

N/A

Retaining Rings

786060-1

Actuator

790199-3 790199-4 790199-5 790199-6 790199-8

Blade & Pin

RFC11AC1P0C RFC11AC1R0C RFC11T1R0C RFC11T1P0C

Slip Ring

N/A

Bulkhead

802219-1 802219-2

Spinner

802313-1 802313-2

Dome Cover

N/A

Brush Block

802315-1 802315-2

Military Aircraft

CASA CN-235-300

Model No.

14RF-37

Prop CMM

61-13-03

Control

782490-57

Propeller

782750-14

Hub

814721-1 814721-2

Transfer Tube

N/A

Adjusting Nut

N/A

Actuator

790199-7 790199-9

Blade & Pin

RFA12A1P0C

Bulkhead

N/A

Spinner

N/A

Dome Cover

N/A

Brush Block

775689-4 820507-1

CASA C-295

Model No.

568F-5

Prop CMM

61-13-12

Control

N/A

Propeller

820522-1 820522-2

Hub

815470-2

Transfer Tube

815587-1 815587-3

Adjusting Nut

814754-1

Actuator

815585-3 815585-4

Blade & Pin

R815505-4 R815505R4 R815505S4 R815505R4W R815505S4W R815505-7 R815505-8

Bulkhead

820482-1

Spinner

810591-1

Dome Cover

815531-1

Brush Block

820511-1

CASA CN-235

Model No.

14RF-21

Prop CMM

61-13-03

Control

782490-2 782490A2 782490-16 782490A16 782490-27 782490A27 782490-38 782490A38 782490-49 782490A49

Propeller

782750-3 782750-4 782750-5 782750-6 782750-7 782750-8 782750-12

Hub

782501-6 782501-7 814721-1 814721-2

Transfer Tube

N/A

Adjusting Nut

N/A

Actuator

790199-1 790199-2 790199-3 790199-5 790199-6

Blade & Pin

RFC11L1R0C RFC11P1R0C RFC11R1ROC RFC11V1ROC RFC11V1POC RFC11W1ROC RFC11W1POC RFC11Y1ROC RFC11Y1POC RFC11Z1ROC RFC11Z1POC

Bulkhead

N/A

Spinner

N/A

Dome Cover

N/A

Brush Block

775689-1 775689-2 775689-4

General Aviation
and Aero Technologies

SENSENICH

Model

Multiple ALL MODELS OVERHAUL, REPAIR, BENCH CHECK

Propeller

Email for capabilities

HARTZELL

Model

Multiple ALL MODELS OVERHAUL, REPAIR, BENCH CHECK

Propeller

Email for capabilities

MCCAULEY

Model

Multiple ALL MODELS OVERHAUL, REPAIR, BENCH CHECK

Propeller

Email for capabilities
